VNM Direct Drive Xtreme – (32 Nm) High-Torque Sim Racing Wheelbase
VNM Direct Drive Xtreme – (32 Nm) High-Torque Sim Racing Wheelbase
Couldn't load pickup availability
Product Overview
Built for serious sim racers demanding peak precision and force feedback power, the VNM Direct Drive Xtreme 32 Nm wheelbase delivers elite-grade performance. With 32 Nm of torque, integrated high-speed control electronics, and support for advanced telemetry, this wheelbase pushes realism and responsiveness to the next level.
Key Features
-
32 Nm Peak Torque — delivers strong, detailed feedback even under high loads.
-
Industrial Servo Motor — custom smooth motor, 5 pole pairs, designed for reliability and responsiveness.
-
High-Precision 23-Bit Absolute Encoder — 8,388,608 counts per revolution ensures ultra-fine feedback resolution.
-
Integrated Controller (480 MHz MCU) — handles motor control + force feedback processing in one board.
-
Customizable Force Feedback Profiles — tune 11 game effects & 4 user effects, plus adjust smoothness, damping, inertia & friction.
-
Experimental & Telemetry Features — includes crash effect reduction, telemetry-based FFB support (iRacing, ACC, AC, rFactor 2, Le Mans Ultimate).
-
Upgrade Option: Industrial Slip Ring — allows you to use third-party wheels while maintaining clean wiring.
-
Compact Footprint — main body measures 130 × 130 × 231 mm (without QR side base).
-
Robust Build & Packaging — weighs ~16 kg including box; includes power adapter, USB cables, emergency stop, quick release base side, manuals, etc.
Specifications
| Spec | Detail |
|---|---|
| Peak Torque | 32 Nm |
| Motor Type | Custom smooth industrial servo, 5 pole pairs |
| Encoder | 23-bit absolute (8,388,608 CPR) |
| Controller | Integrated 480 MHz MCU |
| Dimensions | 130 × 130 × 231 mm (body) |
| Weight (Box incl.) | ~16 kg |
| Packaging Box | 50 × 36 × 25 cm |
| Included Items | Wheelbase, power adapter, USB A-B cable, USB A-C cable, EMC stop button, quick release (base side), manuals, etc. |
| Upgrade Options | Slip ring for third-party steering wheels |
| Telemetry / FFB Support | iRacing, ACC, Assetto Corsa, rFactor 2, Le Mans Ultimate, etc. |
Compatibility & Use Cases
-
Compatible with PC / Windows sim environments via USB.
-
Supports telemetry feedback for sim titles like iRacing, Assetto Corsa, ACC, rFactor 2, etc.
-
Can integrate into existing sim cockpits via M8 × 4 mounting holes.
-
Upgradable to support alternate steering wheel brands using slip ring.
-
Ideal for users moving from belt/gear drives to high-end direct drive setups, or for those wanting to future-proof their rig.
Why Choose the VNM Direct Drive Xtreme 32 Nm?
This wheelbase is for racers who want maximum immersion, detailed feedback fidelity, and tweakability. With industrial-grade hardware, precise encoding, and customization depth, it’s designed for those who take simulation seriously. It gives you the strength to feel every nuance on track and the flexibility to evolve your setup over time.
